EAGLE – Gerbers Itead

 1. Gerber files needed for 1-layer PCB boards:Bottom/Top layer: pcbname.GBL/GTLSolder Stop Mask Bottom/top: pcbname.GBS/GTSSilk Bottom/Top: pcbname.GBO/GTO NC Drill: pcbname.TXT 2. Gerber files needed for 2-layer & 4-layer PCB boards: Top layer: pcbname.GTL Inner Layer 1: pcbname.GL1 (for 4-layer board) Inner Layer 2: pcbname.GL2 (for 4-layer board) Bottom layer: pcbname.GBL Solder Leer más…
